25/25 PPM
Up to 1,200 dpi
Ethernet,
USB 2.0
LCD Touch Panel
Up to A3
(297 × 431.8 mm)
A3 full size
1,000 sheets (standard trays) 150 sheets (multi-purpose tray)
Main tray: 52–256 gsm
Multi-purpose: up to 300 gsm
| COPY | D420 | D421 | D422 | |
|---|---|---|---|---|
| Speed (Color / Black and White) | 25/25 PPM | 30/30 PPM | 36/36 PPM | |
| Warm Up Time | 18 Seconds or Less | 18 Seconds or Less | 20 Seconds or Less | |
| First Copy Speed (Color / Black and White) | 7.5 sec / 6.1 sec | 7.3 sec / 5.6 sec | 6.9 sec / 5.3 sec | |
| Memory | 2GB Standard (Upgradable up to 4GB) | |||
| HDD | 250GB | |||
| Double Sided Printing | Built In | |||
| Paper Capacity | Tray 1 & 2 | 1,000 sheets(500 sheets x 2 Tray ,80 gsm) Standard | ||
| Manual Tray | 150 sheets (80 gsm) | |||
| RADF | 100 sheets (80 gsm) | |||
| Paper Handling | Tray 1 & 2 | A5 to A3 / 8.5" x 5.5" to 11" x 17" | ||
| Manual Tray | 8.5" x 5.5" to 12" x 18" , 11.65" x 42" (banner) | |||
| Weight | 52 - 256 gsm (Tray) & 60 - 300 gsm (Manual Tray) | |||
| Toner | Black & White | 28,000 sheets (based on ISO 5% chart) | ||
| Colored | 26,000 sheets (based on ISO 5% chart) | |||
| Drum | Black & White | 90,000 copies | 120,000 copies | 120,000 copies |
| Colored | 55,000 copies | 75,000 copies | 90,000 copies | |
| Developing Unit | Black & White | 100,000 sheets | ||
| Colored | 100,000 sheets | |||
| Power Consumption | 1.58 KW (220V) | |||
| Display | 9 inch Color LCD | |||
| Size (W x D H) | 615 x 685 x 906 mm (Body + RADF) | |||
| 615 x 685 x 1152 mm (Body + RADF + Table) | ||||
| 94 Kg(Body + RADF) / 104 Kg (Body + RADF + Table) | ||||
| SCAN | D420 | D421 | D422 | |
|---|---|---|---|---|
| Scan Mode | Color, Gray Scale, Black, and White | |||
| Speed | (Based on 300 dpi) | 80/80 IPM | ||
| Resolution | Push | 200/300/400/600 dpi | ||
| Pull | 100/200/300/400/600 dpi | |||
| Interface | Ethernet 10Base -Tx / 100Base - Tx / 1000 Base - Tx | |||
| Protocol | TCP/IP (IPv4, IPv6) Email, FTP, SMB, WebDAV | |||
| Compatability OS | Windows Vista / Vista (x64) /7/7(x64)/8/8(x64)/8.1/8.1 (x64),10,11 | |||
| Supported Formats | TIFF, JPEG, PDF, Compact PDF, OOXML (pptx, docx, xlsx) XPS, Compact XPS, Searchable PDF* PDF/A*, Linearized PDF* | |||
| D420 | D421 | D422 | ||
|---|---|---|---|---|
| Speed (Color / Black and White) | 25/25 PPM | 30/30 PPM | 36/36 PPM | |
| Resolution | 1,200 dpi | |||
| Memory | 2GB | |||
| Interface | Ethernet 10Base - Tx/ 100Base - Tx/ 1000Base - Tx
USB 2.0 (High-Speed) | |||
| Fax (Optional) | D420 | D421 | D422 | |
|---|---|---|---|---|
| Communication Lines | PSTN (Public Switch Telephone Network) PBX (Private Branch Exchange), G3 (Fax Line) | |||
| Transmission Speed | 2.4 - 33.6 kpbs | |||
| Transmission Time | 2 Seconds or less (A4, V.34, 33.6 kbps, JBIG) | |||
| Data Compression Format | MH, MR, MMR, JBI | |||
| Communication Mode | ECM / G3 | |||
| Transmission Flat Bed | Width 279 x Length 431.8 mm (A3 or 11” x 17”) | |||
| RADF | Width 279 x Length 1,000 mm | |||
Work faster with an intuitive control panel and customizable shortcuts for common tasks like copying, duplex printing, and scanning. Quickly convert documents into organized digital files with smooth full-color scanning and save them in formats like PDF, JPEG, or TIFF—keeping your workflow simple and efficient.
Keep tasks flowing with a system built for efficiency and ease. Move from printing to scanning to copying without interruptions, while maintaining clear, professional results every time. Its balanced performance and straightforward operation help teams stay focused and get more done with less effort.
